Cytech Outdoor Server Cabinet

The Cytech Outdoor Server Cabinet is a robust and secure solution designed to protect your sensitive IT equipment in outdoor environments. Engineered with durability and functionality in mind, this cabinet is ideal for a variety of applications including telecommunications, data centers, and industrial settings.

Key Features

Weatherproof Design

• Material: Galvanized steel with a powder-coated finish

• Ingress Protection: IP65 rating, ensuring protection against dust and low-pressure water jets

• Operating Temperature Range: -40°C to +60°C

Thermal Management

• Cooling Options: Built-in ventilation fans, optional air conditioning unit (500W to 2000W capacity)

• Ventilation: High-efficiency air filters to maintain clean airflow

Security

• Locking Mechanism: Multi-point locking system with padlockable handles

• Additional Security: Tamper-proof latches, optional surveillance cameras and intrusion alarms

Flexible Configuration

• Rack Units: Available in sizes from 6U to 42U

• Mounting Rails: Adjustable 19-inch rack rails

• Cable Management: Integrated cable entry points with grommets

Durability

• Construction: Corrosion-resistant materials with UV-resistant powder coating

• Strength: Reinforced frame for enhanced structural integrity

Ease of Maintenance

• Access: Removable side panels and rear access door

• Serviceability: Tool-less access to equipment and cable management

Compliance

• Standards: Complies with industry standards such as NEMA 4 and ETSI EN 300 019




Technical Specifications

• Dimensions (HxWxD):

• 6U: 300mm x 600mm x 600mm (11.8" x 23.6" x 23.6")

• 10U: 500mm x 600mm x 600mm (19.7" x 23.6" x 23.6")

• 12U: 600mm x 600mm x 600mm (23.6" x 23.6" x 23.6")

• 14U: 700mm x 600mm x 600mm (27.6" x 23.6" x 23.6")

• 16U: 800mm x 600mm x 600mm (31.5" x 23.6" x 23.6")

• 18U: 900mm x 600mm x 600mm (35.4" x 23.6" x 23.6")

• 22U: 1100mm x 600mm x 600mm (43.3" x 23.6" x 23.6")

• 24U: 1200mm x 600mm x 600mm (47.2" x 23.6" x 23.6")

• 26U: 1300mm x 600mm x 600mm (51.2" x 23.6" x 23.6")

• 30U: 1500mm x 600mm x 600mm (59.1" x 23.6" x 23.6")

• 32U: 1600mm x 600mm x 600mm (63.0" x 23.6" x 23.6")

• 36U: 1800mm x 600mm x 600mm (70.9" x 23.6" x 23.6")

• 42U: 2000mm x 600mm x 800mm (78.7" x 23.6" x 31.5")

• Weight Capacity: Up to 1500 kg (3307 lbs)

• Power Options:

• Single-phase or three-phase power supply

• Integrated PDU (Power Distribution Unit) with up to 24 outlets

• Cooling Capacity: 500W to 2000W depending on model and configuration




Whether you need to deploy a network infrastructure in a remote location or protect your IT assets in challenging environments, the Cytech Outdoor Server Cabinet provides a dependable and versatile solution to meet your needs.
